Standalone Waterproof Metal Keypad RFID Access Controller
- Dimension:120×80×22(mm)
- Working voltage:12V DC
- Working current:<60mA
- Cards capacity:2000pcs
- Inducation range:ID 5-8cm
- Door Delay time:0~99 seconds(adjustable)
- Open mode:Card/ Super password/UID+Password/card+password
- Card type:EM ID card (125khz)
- Output connectors:Door release button/ Door sensor/Door bell/alarm siren/ tamper
- Color:Silver
- Suit for:home/ office
Standalone Waterproof Metal Keypad RFID Access Controller
| Specification | |
| Product name |
Standalone Waterproof Metal Keypad RFID Access Controller |
| Model | EA-87B |
| Dimension |
120×80×22(mm) |
| Working voltage |
12V DC |
| Working current |
<60mA |
| Cards capacity | 2000pcs |
| Inducation range |
ID 5-8cm |
| Door Delay time |
0~99 seconds(adjustable) |
| Open mode | Card/ Super password/UID+Password/card+password |
| Card type | EM ID card (125khz) |
| Output connectors | Door release button/ Door sensor/Door bell/alarm siren/ tamper |
| Color | Silver |
| Suit for | home/ office |
| Shell Material | stainless steel |
| Working temperature | -10 ℃~50 ℃ |
| Net weight | 0.8kg |
What's the features of our Standalone Waterproof Metal Keypad RFID Access Controller?
1.Low power consumption: less than 30mA standby current
2.Luminous keyboard: the night can also operate keyboard
3.User capacity: support 2,000 users
4.Independent password: can use password which irrelevant with the card to open the door
5.User modification password: Users can revise the door password
6.Search speed: charge to open the door time less than 0.1 S.
7.Output short circuit protection: electric lock or alarm output circuit within 100μS when shut
down automatically output
8.Wiegand output: With Wiegand output interface,WG26 card number or WG34 buttons output
9.Usable keyboard delete card number:After card is lost, usable keyboard delete card,
Thoroughly eliminate safety lapses
10.The demolition alarm:Illegal dismantling machine, built-in alarm sound buzzer
11.The bell button and interface: key and circuit segregation, external any the doorbell.
IN-KIND SHOOTING
APPLICATION
SHOW CASES
OFFICE SHOW
CUSTOMERS
EXHIBITION
CERTIFICATION
HOW TO COOPERATE
FAQ
Q:Can I have a sample order?
A:Yes, we are willing to offer trial sample order to you for quality test. Mixed samples are acceptable.
Q:What is the lead time?
A:Sample needs 1-3 working days, mass production time needs 10-15 working days.
Q:What is your MOQ?
A:No MOQ limit.The more quantity the more discounts.
Q:How do you ship the goods and how long does it take arrive?
A:The sample will be sent to you by optional shipping service (couriers, air, and sea),or appointed by buyer,7-15 days.
Q:How will we proceed the order if I have logo to print?
A:Firstly, we will prepare artwork for visual confirmation. If the color and position are right, we would make sampling firstly from silk print factory and take picture for your second confirmation before mass production.
