EB-189 Wired Digital Vibrate Detector Sensor
- EB-189 Wired Digital Vibrate Detector Sensor
- Product dimension:26×86×25mm
- Operatting voltage:DC 9-16V
- Operatting currient:15mA
- Alarm contact:NC,12VDC,/max100mA
- Tamper contact:NC,12VDC,/max100mA
- Alarm time:2.2 s
- Pre-alarm time:1 min
- Detection range:1.5-3.5m(depend on the material)
- Induction method:acoustic sensors
- Operatting temperature:-20°C~50°C
Vibrate sensor and indoor safety PIR Sensor EB-189
EB-189's main parameter
| Specification | |
| Product name | Wired acoustic vibration detector for violent destruction alarm |
| Model | EB-189 |
| Size | 85*26*25mm |
| Working voltage | 9~16V DC |
| Current | 11mA(Under 12V DC power supply) |
| Alarm contact | 0.1A,24V, NC |
| Tamper contact | 0.1A,24V,NC |
| Installation way | surface-mounted |
| Alarm time | 2.2s min |
| Working temperature | -10℃~50℃ |
| Storage temperature | -25℃~65℃ |
| Color | White |
| Weight | 0.1kg |
Features
EB-189 digital vibratory detector use the international advanced photoelectric sensor elements with CPU processing technology to ensure the rigorous monitoring for the protective coverage. adjustable detective sensitivity in order to balance point correctly. It is applicable to automatic teller machine(ATM) and wall and Glass and strongbox etc. and prevent any action of knock and destruction.
