WIFI App control cordless GSM wireless home alarm system kit
- Specification
- Product name：LCD display WIFI+GSM+App control alarm kit for home alarm system
- Model：EB-821
- Box case dimension：210*150*75(mm)
- Keypad dimension：185×125×14.7mm(L×H×T)
- Power supply ：110V~220V AC or DC 5V(micro USB jack)
- Static current：≤80uA
- Alarm current：≤120mA
- Siren output：<500mA
- Defence zone：Max 100 pcs wireless accessories
- GSM Band ：4-band (850/900/1800/1900Mhz)
- WIFI format：IEEE802.11b/g/n
- Working temperature：0℃~+55℃
- Working humidty：<80%
- System Wireless Frequency：433Mhz(1527 code,330K)
- Backup battery：3.7V/500Ah Lithium battery
- Cellphone App：Andorid & IOS App
- Weight：0.7kg
WIFI App control cordless GSM wireless home alarm system kit
Product Description
| Specification | |
| Product name |
LCD display WIFI+GSM+App control alarm kit for home alarm system |
| Model |
EB-821 |
| box case dimension |
210*150*75(mm) |
| Keypad dimension | 185×125×14.7mm(L×H×T) |
| Power supply | 110V~220V AC or DC 5V(micro USB jack) |
| Static current | ≤80uA |
| Alarm current |
≤120mA |
| Siren output | <500mA |
| Defence zone | Max 100 pcs wireless accessories |
| GSM Band | 4-band (850/900/1800/1900Mhz) |
| WIFI format | IEEE802.11b/g/n |
| Working temperature | 0℃~+55℃ |
| Working humidty | <80% |
| System Wireless Frequency | 433Mhz(1527 code,330K) |
| Backup battery | 3.7V/500Ah Lithium battery |
| Cellphone App | Andorid & IOS App |
| Weight | 0.7kg |
Product Feature
| 1.2.4 inch TFT display screen, concise user interface and menu hint design. |
| 2.Main interface status bar,date/clock indication, fairly obvious alarm host statues. |
| 3.Built-in powerful performance CPU master based on 32-bit Cortex-M3 core. |
| 4.Based on Ucos-III operating system with multitasking design, great user operation experience. |
| 5.WIFI/GSM/3G/GPRS intranet alarm system,support different alarm channels, like APP push/SMS/voice monitoring/intranet center etc. to ensure the alarm performance stable and reliable. |
| 6.Support SMS arm/disarm and voice arm/disarm. |
| 7.Support up to 100 learning/storage location for remote controls, RFID cards and wireless detectors. |
| 8.Support many defense zones,such as gate,SOS,bedroom,window, balcony, perimeter, smoke, gas, carbon monoxide,water leaking,etc. |
| 9.Support the main power malfunction, backup power shortage,tamper alarm and other extended alarm. |
| 10.Support entry/exit zone, inddor zone, perimeter zone, 24-hour zone..etc. |
| 11.Up to 5 groups preset alarm phone numbers, SMS on/off and dial on/off can be set respectively. |
| 12.Support external wireless siren,timing arm and disarm. |
| 13.Can store and inquire daily operation records and alarm records |
| 14.GSM network clock synchronization, to ensrue accurate clock, and support country time zone setting. |
| 15.Support multi-language menu display, voice prompts and alarm SMS setting. |
| 16.Can record 20 seconds voice message and alarm voice. |
| 17.Telephone function,support 5 groups re-dial number. |
| 18.User-friendly APP operation experience and user interface, the host will send Arm/Disarm message to App |
| 19.Support App Remote Arm/Disarm, parameter setting and accessory management. |
| 20.Online GPRS to obtain equipment status, automatic alarm when offline. |
| 21.Reserved remote GPRS TCP/UDP protocol channel, compatible with multiple alarm center networking protocol to facilitate network alarm. |
Product Display
IN-KIND SHOOTING
Application
INSTRUCTIONS FOR USE
Show Cases
RELATED ITEMS SHOWCASES
Company Information
OFFICE SHOW
CUSTOMERS
EXHIBITION
CERTIFICATION
Our Services
HOW TO COOPERATE
FAQ
FAQ
Q:Can I have a sample order?
A:Yes, we are willing to offer trial sample order to you for quality test. Mixed samples are acceptable.
Q:What is the lead time?
A:Sample needs 1-3 working days, mass production time needs 10-15 working days.
Q:What is your MOQ?
A:No MOQ limit.The more quantity the more discounts.
Q:How do you ship the goods and how long does it take arrive?
A:The sample will be sent to you by optional shipping service (couriers, air, and sea),or appointed by buyer,7-15 days.
Q:How will we proceed the order if I have logo to print?
A:Firstly, we will prepare artwork for visual confirmation. If the color and position are right, we would make sampling firstly from silk print factory and take picture for your second confirmation before mass production.
