Two CH 12V/24V 433Mhz/315Mhz wireless universal remote controllerTwo CH 12V/24V 433Mhz/315Mhz wireless universal remote controllerTwo CH 12V/24V 433Mhz/315Mhz wireless universal remote controllerTwo CH 12V/24V 433Mhz/315Mhz wireless universal remote controllerTwo CH 12V/24V 433Mhz/315Mhz wireless universal remote controllerTwo CH 12V/24V 433Mhz/315Mhz wireless universal remote controllerTwo CH 12V/24V 433Mhz/315Mhz wireless universal remote controller

Two CH 12V/24V 433Mhz/315Mhz wireless universal remote controller

  • Model EA-11-2-12, EA-11-2-24
  • Size
  • Receiver:68*48*20(mm)
  • Sender:53*23*10(mm)
  • Receiver:68*48*20(mm)
  • Sender:53*23*10(mm)
  • Working voltage 12V DC  24V DC
  • Working Current <6MA
  • Power consumption 10mW 10mW
  • Max connect remote controller 1 Receiver max match 30 pcs transmitters
  • Wireless frequency 315Mhz/433Mhz(optional)
  • Communication distance 100m in open air
  • Working temperature  -20℃~50℃
  • Storage temperature  -25℃~65℃
  • Operating humidity 95%

Two CH  12V/24V 433Mhz/315Mhz  wireless universal remote controller

Product Introduction

.png

Specification
Product name  2 Channel remote control device ,remote controller for Access control systemcontrol system
Model EA-11-2-12 EA-11-2-24
Size

Receiver:68*48*20(mm)

Sender:53*23*10(mm)

Receiver:68*48*20(mm)

Sender:53*23*10(mm)

Working voltage 12V DC  24V DC
Working Current <6MA  <6MA
Power consumption 10mW 10mW
Max connect remote controller 1 Receiver max match 30 pcs transmitters 1 Receiver max match 30 pcs transmitters
Wireless frequency 315Mhz/433Mhz(optional) 315Mhz/433Mhz(optional)
Communication distance 100m in open air 100m in open air
Working temperature  -20℃~50℃  -20℃~50℃
Storage temperature  -25℃~65℃  -25℃~65℃
Operating humidity 95%  95%
Color  White  White
Weight  85g 85g
Product Feature

What"s the features of our Two CH  12V/24V 433Mhz/315Mhz  wireless universal remote controller?


Product Display

IN-KIND SHOOTING

1120

Application

APPLICATION

1122

Show Cases

SHOW CASES

1112

Company Information

OFFICE SHOW

1zong

CUSTOMERS

3zong

EXHIBITION

4zong

CERTIFICATION

2

Our Services

HOW TO COOPERATE

FAQ

FAQ

Q:Can I have a sample order?

A:Yes, we are willing to offer trial sample order to you for quality test. Mixed samples are acceptable.

Q:What is the lead time?

A:Sample needs 1-3 working days, mass production time needs 10-15 working days.

Q:What is your MOQ?

A:No MOQ limit.The more quantity the more discounts.

Q:How do you ship the goods and how long does it take arrive?

A:The sample will be sent to you by optional shipping service (couriers, air, and sea),or appointed by buyer,7-15 days.

Q:How will we proceed the order if I have logo to print?

A:Firstly, we will prepare artwork for visual confirmation. If the color and position are right, we would make sampling firstly from silk print factory and take picture for your second confirmation before mass production.

How to contact us?

Click the enter send us inquiry below.

Shenzhen MINGQIAN Technology Co., LTD.

Tel:+8613326796950

Contact Person:Tracy Lin

PDF Show:PDF
