Metal Frame Dual Frequency125khz & 13.56mhz Rfid Door Access control Card Reader
- Model number:MQ-714KG
- Card type:ID Card (125Khz)&IC card(13.56MHz)
- Power supply:DC12V
- Working current:<200mA
- Protocol:ISO / IEC14443A, ISO / IEC14443B,
- WG output format: WG34/26 adjustable
- Compatible card type: C,ID,CPU,Desfir Card
- Reading distance:0-5CM
- Communication distance:<80m(between card reader and controller)
- Dimension:90mm*90mm*20.8mm(Error+0.5mm)
- Wires ports:7 wires
- Contact output:12V+(Red wire)/GND(Black wire)/D0(Green)/D1(White)Buzzer(Purple)/Beeper(Grey)WG 26(Yellow)
- Suitable for:Door access control system
- Material:Metal housing+ PCB board
- Housing color:Golden frame+ Black panel
- Working temperature:20°C~+60°C
- Weight:0.2kg
- Warranty: 1 years warranty
- OEM:Welcome OEM
Metal Frame Dual Frequency125khz & 13.56mhz Rfid Card Reader with Touch Keyboard Button for WG Access Controller MQ-714KG
MQ-714KG's main parameter
| Product Name: | Metal Frame Dual Frequency125khz & 13.56mhz Rfid Card Reader with Touch Keyboard Button for WG Access Controller |
| Model number: | MQ-714KG |
| Card type: | ID Card (125Khz)&IC card(13.56MHz) |
| Power supply: | DC12V |
| Working current: | <200mA |
| Protocol: | ISO / IEC14443A, ISO / IEC14443B, |
| WG output format: | WG34/26 adjustable |
| Compatible card type: | IC,ID,CPU,Desfir Card |
| Reading distance: | 0-5CM |
| Communication distance: | <80m(between card reader and controller) |
| Dimension: | 90mm*90mm*20.8mm(Error+0.5mm) |
| Wires ports: | 7 wires |
| Contact output: |
12V+(Red wire)/GND(Black wire)/D0(Green)/D1(White) Buzzer(Purple)/Beeper(Grey)WG 26(Yellow) |
| Suitable for: | Door access control system |
| Material: | Metal housing+ PCB board |
| Housing color: | Golden frame+ Black panel |
| Working temperature: | -20°C~+60°C |
| Weight: | 0.2kg |
| Warranty: | 1 years warranty |
| OEM: | Welcome OEM |
What features MQ-714KG have?
How about other choice?
Metal Frame Dual Frequency125khz & 13.56mhz Rfid Card Reader with Touch Keyboard Button for WG Access Controller
Metal Frame Dual Frequency125khz & 13.56mhz Rfid Card Reader with Touch Keyboard Button for WG Access Controller
Metal Frame Dual Frequency125khz & 13.56mhz Rfid Card Reader with Touch Keyboard Button for WG Access Controller
