Outdoor wireless pir motion sensor for home gsm alarm systemOutdoor wireless pir motion sensor for home gsm alarm systemOutdoor wireless pir motion sensor for home gsm alarm systemOutdoor wireless pir motion sensor for home gsm alarm systemOutdoor wireless pir motion sensor for home gsm alarm systemOutdoor wireless pir motion sensor for home gsm alarm system

Outdoor wireless pir motion sensor for home gsm alarm system

  • Product name: Outdoor wireless pir motion sensor for home gsm alarm system
  • Model :EB-191
  • Dimension:110×70×40(mm)
  • Operating voltage:3.7V 800mA rechargeable Li-Ion battery
  • Static current : <=15mA
  • Alarm current: <=50mA
  • Detecting Distance: 10m
  • Detecting angle :110°
  • Transmitting frequency :433Mhz/868Mhz(1527 coding chip)(optional)
  • Battery charge time :8 hours
  • Transmitting distance: 150m(in open area)
  • Installation height : 2~2.4m
  • Installation mode: Wall mounted
  • Color: White shell
  • Usage :Home alarm system
  • Material : fireproof ABS housing
  • Net weight: 0.17kg

Outdoor wireless pir motion sensor for home gsm alarm system

191



Product name

Outdoor wireless pir motion sensor for home gsm alarm system

Model

EB-191

Dimension

110×70×40(mm)

Operating voltage

3.7V 800mA rechargeable Li-Ion battery

Static current  <=15mA
Alarm current <=50mA
Detecting Distance

10m

Detecting angle

110°

Transmitting frequency

433Mhz/868Mhz(1527 coding chip)(optional)

Battery charge time

8 hours

Transmitting distance 150m(in open area)
Installation height  2~2.4m
Installation mode Wall mounted
Color White shell
Usage Home alarm system
Material  fireproof ABS housing
Net weight

0.17kg



Product Features

What Features of our pir motion sensor EB-191?

 1913



Product Picture

IN-KIND SHOOTING



 1911







APPLICATION

1915

Related Items

SHOW CASE

1914

Company Information

OFFICE SHOW

1zong

CUSTOMER

photobank (4)

EXHIBITION

4zong

CERTIFICATE

2

HOW TO COOPERATION

How to coperation

FAQ

FAQ

Q:Can I have a sample order?

A:Yes, we are willing to offer trial sample order to you for quality test. Mixed samples are acceptable.



Q: What is the lead time?

A:Sample needs 1-3 working days, mass production time needs 10-15 working days for order less than 5000pcs.



Q: Do you have any MOQ limit?

A:EXW MOQ is 100pcs under blank box.



Q: How do you ship the goods and how long does it take arrive?

A:The sample will be sent to you by optional shipping service (couriers, air, and sea). The delivery time depends on the shipping service.



Q:How will we proceed the order if I have logo to print?

A:Firstly, we will prepare artwork for visual confirmation. If the color and position are right, we would make sampling firstly from silk print factory and take picture for your second confirmation before mass production.



Q: Does alarm panel work with any sensor?

A:The alarm panel can work with all dry contact wired detectors and wireless detector, including almost all

of the wireless sensors from Chinese manufacturers. The wireless encode and decode is EV1527 or our wireless sensors.
