Standalone Waterproof Metal Keypad RFID Access ControllerStandalone Waterproof Metal Keypad RFID Access ControllerStandalone Waterproof Metal Keypad RFID Access ControllerStandalone Waterproof Metal Keypad RFID Access ControllerStandalone Waterproof Metal Keypad RFID Access ControllerStandalone Waterproof Metal Keypad RFID Access Controller

Standalone Waterproof Metal Keypad RFID Access Controller

  • Dimension:120×80×22(mm)
  • Working voltage:12V DC
  • Working current:<60mA
  • Cards capacity:2000pcs
  • Inducation range:ID 5-8cm
  • Door Delay time:0~99 seconds(adjustable)
  • Open mode:Card/ Super password/UID+Password/card+password
  • Card type:EM ID card (125khz)
  • Output connectors:Door release button/ Door sensor/Door bell/alarm siren/ tamper
  • Color:Silver
  • Suit for:home/ office

Standalone Waterproof Metal Keypad RFID Access Controller

Specification
Product name

Standalone Waterproof Metal Keypad RFID Access Controller

Model EA-87B
Dimension

120×80×22(mm)

Working voltage

12V DC

Working current

<60mA

Cards capacity  2000pcs
Inducation range

ID 5-8cm

Door Delay time

0~99 seconds(adjustable)

Open mode  Card/ Super password/UID+Password/card+password
Card type  EM ID card (125khz)
Output connectors Door release button/ Door sensor/Door bell/alarm siren/ tamper
Color Silver
Suit for home/ office
Shell Material  stainless steel
Working temperature -10 ℃~50 ℃
Net weight 0.8kg

What's the features of our Standalone Waterproof Metal Keypad RFID Access Controller?

002145

1.Low power consumption: less than 30mA standby current

2.Luminous keyboard: the night can also operate keyboard

3.User capacity: support 2,000 users

4.Independent password: can use password which irrelevant with the card to open the door

5.User modification password: Users can revise the door password

6.Search speed: charge to open the door time less than 0.1 S.

7.Output short circuit protection: electric lock or alarm output circuit within 100μS when shut

   down automatically output

8.Wiegand output: With Wiegand output interface,WG26 card number or WG34 buttons output

9.Usable keyboard delete card number:After card is lost, usable keyboard delete card,

  Thoroughly eliminate safety lapses

10.The demolition alarm:Illegal dismantling machine, built-in alarm sound buzzer

11.The bell button and interface: key and circuit segregation, external any the doorbell.
